Forged flange enquiries for pipe and vessel connections can involve different flange types, dimensional standards, materials, facings and inspection requirements. Use this overview to identify a relevant flange type and prepare an item list or drawing so BLD can review each requested combination for feasibility.
For ASME RFQ routing, B16.5 tabulates Classes 150 to 1500 at NPS 1/2 to 24 and Class 2500 at NPS 1/2 to 12; B16.47 tabulates Classes 75 to 900 at NPS 26 to 60. EN 1092-1, DIN and GOST 33259/12820/12821 requests follow their exact DN/PN table or project drawing. These are published standard scopes, not a promise that BLD can supply every grade and facing combination. Above NPS 12 we forge Class 2500 flanges to your drawing and design calculation. We supply ASME B16.47 Series A and Series B flanges across NPS 26 to NPS 60, in the classes and sizes the standard tabulates for each series. Our D51 mill rolls rings up to 1,500 mm OD and 240 mm thick; larger rings are forged by partner forges near our plant in Dingxiang. BLD reviews each requested grade, facing, bore, quantity and inspection scope before confirming feasibility.
Typical work is pipeline, valve, pump, pressure vessel and EPC packages in petrochemical and power projects. Whatever the type, the quotation turns on the same items: flange type, bore or schedule, facing (RF, FF or RTJ), drilling pattern and material grade - with MTC EN 10204 3.1, a dimensional report, PMI for alloy grades and UT, MT or PT added when the project specification calls for them.
Product family: Flanges
Send forged flange RFQs with standard, size, pressure class, material grade, facing, bore and quantity for direct review before quotation.
| Scope and rating | |
|---|---|
| Size and rating review | Published ASME scope for RFQ routing: B16.5 Classes 150 to 1500 at NPS 1/2 to 24 and Class 2500 at NPS 1/2 to 12; B16.47 Classes 75 to 900 at NPS 26 to 60. EN/DIN/GOST DN/PN and BLD feasibility require the exact standard or drawing. |
| Standards and materials | |
| Standards / drawings |
|
| Material grades |
|
| Geometry, tolerance and inspection | |
| Critical dimensions | Flange type, bore or schedule, facing RF/FF/RTJ, drilling pattern, thickness, hub profile and marking. |
| Inspection depth | MTC 3.1, dimensional report, PMI for alloy grades, UT/MT/PT when the project specification requires it. |
| Reviewed before quotation |
|
| Buying logic | |
| Best-fit RFQ | Best for RFQs where the buyer knows the requirement is a forged steel flange but still needs to confirm type, standard and material. |
| Buyer application | Pipe, valve, pump, pressure vessel, petrochemical, power and EPC line-item purchasing. |
Your standard, drawing revision and project specification govern.
Also known as
We confirm each step against your drawing or standard before we quote.
Material grade, heat number, certificate basis and substitution limits are checked against the Forged Flanges drawing or standard before procurement is released.
The forging route is selected around flange type, section thickness, bore allowance, hub or neck geometry and pressure-service requirements.
Heat treatment is planned with the required record package, mechanical testing basis and impact-test condition where low-temperature or alloy service applies.
Rough machining opens reference faces, bore, hub, neck or sealing-face stock needed to control allowance before final flange machining.
Final machining controls facing, bore, bolt pattern, groove, sealing surface and flange-table or drawing tolerances before dimensional inspection is issued.
Inspection covers dimensional report, MTC 3.1, PMI and required UT, MT or PT records before the release documents are matched to the purchase order.
Marking, packing and export documents are prepared by PO line item so the Forged Flanges shipment can clear customs and be identified at site receiving.
List document requirements in the first RFQ; they affect price and schedule.
No. B16.5 and B16.47 tabulate sizes and classes; those are published standard scopes, not a promise that we can supply every grade and facing combination. We review each requested grade, facing, bore, quantity and inspection scope before confirming feasibility.
We forge flanges to your drawing in sizes from NPS 1/2 to NPS 60. We roll rings up to 1,500 mm OD and 240 mm thick on our D51 ring rolling mill. Larger rings, up to 10,000 mm OD and 500 mm thick, are forged by partner forges near our plant in Dingxiang that run presses up to 10,000 t.
Pipeline, valve, pump, pressure vessel and EPC packages in petrochemical and power projects, built to ASME, EN 1092-1, DIN, GOST or project drawings.
Email quote@bldforgedirect.com with standard, drawing, material, quantity and inspection requirements.
